Suzuki Hayabusa Gen 3 2022–2024 Service Repair Manual – PDF Download

Suzuki Hayabusa Gen 3 2022–2024 Service Repair Manual – PDF Download

Regular price $19.99
Regular price Sale price $19.99
Sale Sold out
Taxes included. Shipping calculated at checkout.

🛠️ Suzuki Hayabusa Gen 3 2022–2024 Service Repair Manual – PDF Download

🧰 Factory service manual for the 2022–2024 Suzuki Hayabusa Gen 3 superbike. This professional-grade repair guide covers all aspects of maintenance, diagnostics, and mechanical service for the advanced 1340cc EFI-equipped hyperbike. Perfect for owners, technicians, and performance tuners.

📲 Instant PDF Download – Fully searchable and printable. Works on all computers, tablets, and smartphones.

🔍 Model Background

The Suzuki Hayabusa Gen 3 (2022–2024) represents the latest evolution of one of the most iconic hypersport motorcycles in history. While maintaining its signature aerodynamic silhouette and long-distance speed dominance, the third-generation Hayabusa focuses on refinement, rider control, and electronic sophistication rather than outright top speed.

Powered by a revised 1340cc inline-4 liquid-cooled engine with dual overhead cams and ride-by-wire throttle, the Gen 3 Hayabusa produces around 187 horsepower and even stronger midrange torque. Suzuki retuned the engine for improved low-end response, durability, and real-world performance, making it faster in everyday conditions despite a slight reduction in peak output from Gen 2.

The real transformation comes in the electronics: the Hayabusa now features the Suzuki Intelligent Ride System (S.I.R.S.), which includes launch control, lean-sensitive ABS, cornering traction control, engine brake control, cruise control, quick shifter, and riding modes. The upgraded TFT/LCD instrument panel integrates all functions into a high-tech user interface.

Produced from 2022 through 2024, the third-generation Hayabusa continues its legacy as the ultimate high-speed sport-tourer, now optimized for control, safety, and everyday rideability—while still delivering that unmistakable Hayabusa presence and power.

📆 Model Years Covered:

  • Suzuki Hayabusa Gen 3 – 2022
  • Suzuki Hayabusa Gen 3 – 2023
  • Suzuki Hayabusa Gen 3 – 2024

📘 Manual Details:

  • Engine: 1340cc, 4-cylinder, 4-stroke, DOHC, liquid-cooled
  • Fuel System: Advanced EFI (Electronic Fuel Injection)
  • Ignition: Transistorized electronic ignition system
  • Transmission: 6-speed constant mesh
  • Final Drive: Chain
  • Cooling: Liquid-cooled with radiator and electric fan
  • Front Suspension: Inverted telescopic fork, fully adjustable
  • Rear Suspension: Link-type, coil spring, oil-damped, adjustable
  • Front Brakes: Dual hydraulic disc with Brembo Stylema calipers
  • Rear Brake: Single hydraulic disc
  • Electronic Systems: Suzuki Intelligent Ride System (S.I.R.S)
  • Features: Traction control, cruise control, launch control, engine brake control
  • Electrical: 12V with ECU diagnostics and advanced sensor suite
  • Language: English
  • Pages: 800+

📚 Manual Sections Include:

  • General Information
  • Tools, specifications, maintenance intervals
  • Routine Maintenance
  • Oil change, filters, fluids, tire pressure, torque specs
  • Engine Repair
  • Cylinder head, pistons, valve train, timing chain, crankshaft
  • Fuel & EFI System
  • Fuel pump, injectors, throttle body, ECU diagnostics
  • Transmission & Clutch
  • Clutch assembly, gear shifting, selector drum
  • Cooling System
  • Radiator, thermostat, hoses, fan motor
  • Brake System
  • Master cylinder, calipers, pads, bleeding procedure
  • Chassis & Suspension
  • Fork service, rear shock, linkage, steering head
  • Electrical System
  • Battery, sensors, fuses, relays, complete wiring diagrams
  • Advanced Features
  • S.I.R.S functions, electronic controls, cruise, launch, traction

💾 Format & Compatibility:

  • File Type: PDF (Digital Download)
  • Searchable: ✅ Yes
  • Printable: ✅ Yes – Print entire manual or selected sections
  • Compatible with: Windows, macOS, iOS, Android, Linux

🔍 Keywords:

Suzuki Hayabusa Gen 3 service manual PDF, 2022 Hayabusa repair guide, Gen 3 superbike maintenance, EFI tuning, S.I.R.S. diagnostics, full wiring diagrams

❓ Mini FAQ:

Q: Is this the official Suzuki factory manual?
A: Yes – this is the complete OEM service manual for the Hayabusa Gen 3 models.

Q: Does this cover electronic ride systems and diagnostics?
A: Absolutely – includes full coverage of the S.I.R.S features and advanced electronics.

Q: Can I use this on mobile devices?
A: Yes – it works perfectly on phones, tablets, laptops, and desktops.

🧭 Helpful Resources for Suzuki Motorcycle Owners

🔧 Browse More Suzuki Motorcycle Manuals

Note: While our manuals are designed for DIY use, they do not replace professional mechanical training. If you're unsure about a repair or your motorcycle shows serious issues, we strongly recommend visiting a certified mechanic. These guides are best suited for owners with basic to moderate mechanical experience.

🤝 Want to earn 20%?
Promote this product and earn a 20% commission on every sale you refer!

👉 Join our Affiliate Program here
