Deutz-Fahr Agrokid 220 Tractor 2005–2010 Service Repair Manual – PDF Download

🛠️ Deutz-Fahr Agrokid 220 Tractor 2005–2010 Service Repair Manual – PDF Download

🧰 Complete Factory Workshop Manual – Covers All Deutz-Fahr Agrokid 220 Tractors (2005–2010)
📲 Instant PDF Download – Compatible with Windows, Mac, iOS, Android, and Linux
🔧 Trusted by Technicians, Farmers, and Professional Service Providers

🆔 Serial Numbers Covered:

• Agrokid 220 – S/N Zkds2102V0md20001 and Zkds2902V0md20001

🔍 Model Background

The Deutz-Fahr Agrokid 220 (2005–2010) is a compact and versatile utility tractor designed for specialized agricultural tasks. Manufactured by Deutz-Fahr, this model is particularly well-suited for operations in confined spaces such as orchards, vineyards, and municipal maintenance. The Agrokid 220 combines Deutz-Fahr’s renowned performance with a compact design, offering excellent maneuverability and reliability in various working conditions.

Powered by a Mitsubishi S4L62 ST 1.5-liter, 4-cylinder turbocharged diesel engine, the Agrokid 220 delivers approximately 42.2 horsepower (31.5 kW) at 3,000 RPM. This engine provides a balance of power and fuel efficiency, making it ideal for tasks that demand consistent performance over extended periods. The engine features a bore and stroke of 78 mm × 78 mm, with a torque output of 77.4 lb-ft (105.0 Nm) at 2,100 RPM.

Equipped with a 12-speed shuttle transmission and a 16-speed creeper option, the Agrokid 220 offers versatility in speed control, essential for tasks requiring precise movement. The tractor features a mechanical four-wheel-drive (4WD) system, ensuring excellent traction on various terrains. Power steering and wet disc brakes enhance operator control and safety. The tractor's rear hitch is a Category I, capable of lifting up to 2,646 lbs (1,200 kg), making it suitable for a range of implements and attachments.

With a wheelbase of 68.7 inches (174 cm) and a weight ranging from 2,661 to 3,278 lbs (1,207 to 1,486 kg), the Agrokid 220 offers a low center of gravity, enhancing stability and maneuverability in tight spaces. The tractor's compact dimensions make it ideal for working in narrow rows and confined areas.

Throughout its production run from 2005 to 2010, the Deutz-Fahr Agrokid 220 earned a reputation for its reliability, low maintenance costs, and strong build quality. The comfortable cabin, with optional air conditioning, ensures a pleasant working environment for long hours, while the ergonomic controls allow for ease of use in various agricultural tasks. Today, the Agrokid 220 continues to be valued for its durability and versatility, making it a popular choice for farmers and operators looking for a reliable, compact tractor that excels in tight spaces.

📆 Model Years Covered:

• Deutz-Fahr Agrokid 220 – 2005
• Deutz-Fahr Agrokid 220 – 2006
• Deutz-Fahr Agrokid 220 – 2007
• Deutz-Fahr Agrokid 220 – 2008
• Deutz-Fahr Agrokid 220 – 2009
• Deutz-Fahr Agrokid 220 – 2010

📚 Manual Chapters & Features:

• Introduction & Safety – Factory torque specs, lifting instructions, sealants, lubricants, and hazard info
• Technical Specs – Gearbox and shuttle layouts, PTO speeds, hydraulic flow rates, brake and steering systems
• Calibrations & Diagnostics – Electromagnetic clutch testing, ECU behavior, diagnostic signal mapping
• Engine Service – Full overhaul steps for pistons, camshaft, crankshaft, valves, fuel system, and air intake
• Transmission & PTO – Synchro and non-synchro shift gears, clutch assemblies, mid and rear PTO servicing
• Axle & Brake Systems – Rear axle with planetary gears, front axle, brake system calibration and testing
• Cab & Controls – HVAC system, roof panel, dashboard controls, joystick, and interior service
• Electrical System – Starter, alternator, lighting, switches, connectors, and fuse panel diagnostics
• Hydraulics – Lift valve service, remote valve operation, hydraulic lines and steering support
• Wiring Diagrams – Full cab-to-engine wiring harness layouts, ground points, fuses, and relay positions

💾 Format & Compatibility:

• File Format: PDF
• Language: English
• Fully Bookmarked & Searchable: Yes
• Printable: Yes – Print specific chapters or the full manual
• Compatible With: Windows, macOS, Linux, iOS, Android
• Delivery: 📩 Instant Digital Download

🔍 Keywords:

Deutz-Fahr Agrokid 220 service manual PDF, 2005–2010 tractor repair guide, PTO diagnostics, clutch servicing, engine overhaul, wiring diagrams, ECU testing

❓ Mini FAQ:

Q: Is this the official workshop manual for the Agrokid 220?
A: Yes – it’s the full OEM factory manual used by certified Deutz-Fahr service centers.

Q: Does it include diagnostics and calibration procedures?
A: Absolutely – the manual includes fault tracing, test instructions, and full electronic diagnostics.

Q: Can I view this on mobile devices?
A: Yes – the manual is a standard PDF compatible with smartphones, tablets, and PCs.
