Deutz-Fahr 5690 HTS Combine Harvester 2004–2010 Service Repair Manual – PDF Download

🛠️ Deutz-Fahr 5690 HTS Combine Harvester 2004–2010 Service Repair Manual – PDF Download

🧰 Complete Factory Workshop Manual – Covers All Deutz-Fahr 5690 HTS Combine Harvesters (2004–2010)
📲 Instant PDF Download – Compatible with Windows, Mac, iOS, Android, and Linux
🔧 Perfect for Combine Mechanics, Dealership Service Teams, and Independent Repair Technicians

🔍 Model Background

The Deutz-Fahr 5690 HTS (2004–2010) is a high-performance combine harvester designed for large-scale cereal and maize harvesting operations. Manufactured by Deutz-Fahr, this model is particularly well-suited for high-output harvesting tasks, offering advanced features and exceptional efficiency.

Powered by a 7.1-liter, 6-cylinder Deutz BF6M1013 turbocharged diesel engine, the 5690 HTS delivers an impressive 220 kW (299 hp) at 2,200 RPM. This robust engine provides the necessary power to handle challenging harvesting conditions efficiently. The engine is coupled with a hydrostatic transmission system, offering four forward gears and a maximum speed of 20 km/h, ensuring smooth and responsive operation.

Equipped with a 6.3-meter-wide header, the 5690 HTS is capable of harvesting large swaths of crops, increasing productivity and reducing harvesting time. The machine features a six-straw walker system, providing a total straw walker area of 7.6 m², which enhances separation efficiency and reduces grain loss. The threshing system includes a 60 cm diameter cylinder and a 152 cm width, ensuring thorough threshing of the harvested material.

The grain tank of the 5690 HTS has a capacity of 8,500 liters, allowing for extended harvesting periods without frequent unloading. The unloading system operates hydraulically, facilitating quick and efficient discharge of the harvested grain. The combine harvester is also equipped with a stone trap, air conditioning, and a comfortable cabin, ensuring a pleasant working environment for the operator during long hours in the field.

Throughout its production run from 2004 to 2010, the Deutz-Fahr 5690 HTS earned a reputation for its reliability, low maintenance costs, and strong build quality. Its powerful engine, efficient harvesting capabilities, and operator-friendly features make it a popular choice for farmers seeking a durable and high-performing combine harvester.

📆 Model Years Covered:

• Deutz-Fahr 5690 HTS – 2004
• Deutz-Fahr 5690 HTS – 2005
• Deutz-Fahr 5690 HTS – 2006
• Deutz-Fahr 5690 HTS – 2007
• Deutz-Fahr 5690 HTS – 2008
• Deutz-Fahr 5690 HTS – 2009
• Deutz-Fahr 5690 HTS – 2010

📚 What the Manual Includes:

• Engine Maintenance
• Full service of EMR-managed Deutz engines, fuel systems, timing, belts, and cooling units
• Transmission & Gearbox
• Hydrostatic drive diagnostics, gearbox inspection, PTO clutch servicing, gear shift assembly
• Hydraulic Systems
• Header lift control, reel height hydraulics, service valve units, trailer braking hydraulics
• Threshing & HTS Separation
• Turbo separator repairs, drum speed regulation, concave positioning, straw walker alignment
• Header & Feed Mechanism
• Knife and auger drives, feeder chain tensioning, slip clutch servicing
• Grain Handling Systems
• Tank elevator chains, unloading spout gearbox, discharge tube flow control
• Electrical & EMR Diagnostics
• CAN bus systems, fuse layout, dashboard display tests, sensor signal troubleshooting
• Cab & Operator Console
• HVAC service, overhead control panel, seating and display unit wiring
• Axles, Steering & Braking
• Hydrostatic steering pump, wet disc brakes, rear axle servicing, brake testing
• Maintenance Specs
• Lube charts, torque values, oil types, filter schedules, and adjustment intervals

💾 Format & Compatibility:

• File Format: PDF
• Language: English
• Fully Bookmarked & Searchable: Yes
• Printable: Yes – Print individual chapters or entire document
• Compatible With: Windows, macOS, Linux, iOS, Android
• Delivery: 📩 Instant Digital Download

🔍 Keywords:

Deutz-Fahr 5690 HTS combine harvester manual PDF, 2004–2010 repair guide, turbo separator, EMR fault codes, hydraulic header lift, wiring diagrams, PTO clutch

❓ Mini FAQ:

Q: Does this manual cover the HTS turbo separator system?
A: Yes – it includes full diagrams, adjustments, and repair instructions for the HTS system.

Q: Are EMR engine diagnostics and wiring diagrams included?
A: Absolutely – includes complete CAN bus diagnostics and electrical schematics.

Q: Is it mobile- and tablet-friendly?
A: Yes – works perfectly on any device, including iPhones, Androids, iPads, and desktops.
