Deutz-Fahr 5670 H / HTS Combine Harvester 2004–2010 Service Repair Manual

🛠️ Deutz-Fahr 5670 H / HTS Combine Harvester 2004–2010 Service Repair Manual – PDF Download

🧰 Complete Factory Workshop Manual – Covers Deutz-Fahr 5670 H and 5670 HTS Combine Harvesters (2004–2010)
📲 Instant PDF Download – Compatible with Windows, Mac, iOS, Android, and Linux
🔧 Ideal for Agricultural Mechanics, Harvest Contractors, and Combine Service Technicians

🔍 Model Background

The Deutz-Fahr 5670 H / HTS combine harvester, produced between 2004 and 2010, is a high-performance machine designed for large-scale cereal and maize harvesting operations. Manufactured by Deutz-Fahr, this model is particularly well-suited for high-output harvesting tasks, offering advanced features and exceptional efficiency.

Powered by a 6.1-liter, 6-cylinder Deutz BF6L913 turbocharged diesel engine, the 5670 H / HTS delivers approximately 176 kW (230 hp). This robust engine provides the necessary power to handle challenging harvesting conditions efficiently. The engine is coupled with a hydrostatic transmission system, offering four forward gears and a maximum speed of 20 km/h, ensuring smooth and responsive operation.

Equipped with a 4.8-meter-wide header, the 5670 H / HTS is capable of harvesting large swaths of crops, increasing productivity and reducing harvesting time. The machine features a six-straw walker system, providing a total straw walker area of 7.6 m², which enhances separation efficiency and reduces grain loss. The threshing system includes a 60 cm diameter cylinder and a 152 cm width, ensuring thorough threshing of the harvested material.

The grain tank of the 5670 H / HTS has a capacity of 7,500 liters, allowing for extended harvesting periods without frequent unloading. The unloading system operates hydraulically, facilitating quick and efficient discharge of the harvested grain. The combine harvester is also equipped with a stone trap, air conditioning, and a comfortable cabin, ensuring a pleasant working environment for the operator during long hours in the field.

Throughout its production run from 2004 to 2010, the Deutz-Fahr 5670 H / HTS earned a reputation for its reliability, low maintenance costs, and strong build quality. Its powerful engine, efficient harvesting capabilities, and operator-friendly features make it a popular choice for farmers seeking a durable and high-performing combine harvester.

📎 Variants Covered:

• 5670 H – Standard separation system
• 5670 HTS – Equipped with HTS turbo separator

📆 Model Years Covered:

• Deutz-Fahr 5670 H / HTS – 2004
• Deutz-Fahr 5670 H / HTS – 2005
• Deutz-Fahr 5670 H / HTS – 2006
• Deutz-Fahr 5670 H / HTS – 2007
• Deutz-Fahr 5670 H / HTS – 2008
• Deutz-Fahr 5670 H / HTS – 2009
• Deutz-Fahr 5670 H / HTS – 2010

📚 What the Manual Includes:

• Engine Maintenance
• Servicing of EMR-controlled Deutz diesel engines, including timing, injection, cooling, and belts
• Transmission & Gearbox
• Clutch pack removal, hydrostatic drive diagnostics, gearbox shaft alignment, drive belts
• Hydraulic Systems
• Steering systems, header lift actuators, reel drive hydraulics, service valves
• Threshing & Separation
• HTS and standard drum servicing, concave settings, straw walker tuning, turbo separator details
• Cutting System
• Knife drive gear servicing, feed housing chains, header controls, auger alignment
• Grain Handling
• Grain tank elevator chains, auger gearbox, unloading spout inspection, tank cleaning
• Electrical Systems
• Wiring schematics, EMR engine module testing, sensor fault diagnostics, switchboard controls
• Cabin Controls
• Dashboard unit, operator console, HVAC unit, overhead wiring harness
• Brakes, Steering, Suspension
• Axle inspections, hydraulic steering pump, braking force adjustment
• Service Charts & Specs
• Lubrication points, bolt torques, service intervals, filter specs

💾 Format & Compatibility:

• File Format: PDF
• Language: English
• Fully Bookmarked & Searchable: Yes
• Printable: Yes – Print full chapters or specific pages
• Compatible With: Windows, macOS, Linux, iOS, Android
• Delivery: 📩 Instant Digital Download
