Deutz-Fahr 5660 HTS Combine Harvester 2004–2010 Service Repair Manual

🛠️ Deutz-Fahr 5660 HTS Combine Harvester 2004–2010 Service Repair Manual – PDF Download

🧰 Complete Factory Workshop Manual – Covers All Deutz-Fahr 5660 HTS Combine Harvesters (2004–2010)
📲 Instant PDF Download – Compatible with Windows, Mac, iOS, Android, and Linux
🔧 Ideal for Field Technicians, Harvest Operators, and Deutz-Fahr Combine Specialists

🔍 Model Background

The Deutz-Fahr 5660 HTS combine harvester, produced between 2004 and 2010, is a high-performance machine designed for large-scale cereal and maize harvesting operations. Manufactured by Deutz-Fahr, this model is particularly well-suited for high-output harvesting tasks, offering advanced features and exceptional efficiency.

Powered by a 7.1-liter, 6-cylinder Deutz BF6M1013 turbocharged diesel engine, the 5660 HTS delivers an impressive 191 kW (260 hp) at 2,200 RPM. This robust engine provides the necessary power to handle challenging harvesting conditions efficiently. The engine is coupled with a hydrostatic transmission system, offering four forward gears and a maximum speed of 20 km/h, ensuring smooth and responsive operation.

Equipped with a 5.4-meter-wide header, the 5660 HTS is capable of harvesting large swaths of crops, increasing productivity and reducing harvesting time. The machine features a five-straw walker system, providing a total straw walker area of 7.6 m², which enhances separation efficiency and reduces grain loss. The threshing system includes a 60 cm diameter cylinder and a 152 cm width, ensuring thorough threshing of the harvested material.

The grain tank of the 5660 HTS has a capacity of 7,500 liters, allowing for extended harvesting periods without frequent unloading. The unloading system operates hydraulically, facilitating quick and efficient discharge of the harvested grain. The combine harvester is also equipped with a stone trap, air conditioning, and a comfortable cabin, ensuring a pleasant working environment for the operator during long hours in the field.

Throughout its production run from 2004 to 2010, the Deutz-Fahr 5660 HTS earned a reputation for its reliability, low maintenance costs, and strong build quality. Its powerful engine, efficient harvesting capabilities, and operator-friendly features make it a popular choice for farmers seeking a durable and high-performing combine harvester.

📆 Model Years Covered:

• Deutz-Fahr 5660 HTS – 2004
• Deutz-Fahr 5660 HTS – 2005
• Deutz-Fahr 5660 HTS – 2006
• Deutz-Fahr 5660 HTS – 2007
• Deutz-Fahr 5660 HTS – 2008
• Deutz-Fahr 5660 HTS – 2009
• Deutz-Fahr 5660 HTS – 2010

📚 What the Manual Includes:

• Engine Maintenance
• Full servicing of EMR-controlled Deutz diesel engines, fuel systems, belts, and cooling units
• Transmission & Gearbox
• Hydrostatic transmission layouts, clutch group servicing, shifting control diagnostics
• Hydraulic Systems
• Header lift valves, reel hydraulics, steering cylinder control, PTO actuator hydraulics
• Threshing & Separation
• HTS turbo separator system, concave clearance settings, straw walker adjustment, drum repairs
• Cutting Platform
• Knife gear system, auger drive maintenance, feed elevator drive and belt routing
• Grain Handling
• Grain tank, elevator chains, discharge spout gear group, unloading auger alignment
• Electrical & Electronics
• Complete wiring diagrams, EMR sensor fault tracing, dashboard and relay service
• Cabin & Controls
• Operator interface, HVAC, heater and AC unit controls, overhead panel diagnostics
• Brakes, Steering & Suspension
• Rear axle assemblies, disc brakes, hydrostatic steering pump and line pressure testing
• Maintenance & Technical Data
• Torque specs, fuse locations, maintenance intervals, oil capacity charts

💾 Format & Compatibility:

• File Format: PDF
• Language: English
• Fully Bookmarked & Searchable: Yes
• Printable: Yes – Print full manual or selected pages
• Compatible With: Windows, macOS, Linux, iOS, Android
• Delivery: 📩 Instant Digital Download

🔍 Keywords:

Deutz-Fahr 5660 HTS service manual PDF, 2004–2010 combine harvester repair guide, turbo separator repair, EMR diagnostic system, hydraulic header lift, grain auger

❓ Mini FAQ:

Q: Is this the complete repair manual for the 5660 HTS model?
A: Yes – this is the official workshop manual covering engine, hydraulics, separation, grain, and EMR systems.

Q: Does it include HTS turbo separator repair and PTO actuator service?
A: Absolutely – full component-level coverage is included.

Q: Can I view the manual on a tablet?
A: Yes – the PDF works perfectly on all mobile devices, desktops, and tablets.
